Teams Call Flow Visualizer

# Run in PowerShell as a Teams admin — produces a single teams-callflow.json file
# with full call-flow detail: schedules, holidays, greetings, timers, user forwarding.
if (-not (Get-Module -ListAvailable -Name MicrosoftTeams)) {
  Install-Module MicrosoftTeams -Scope CurrentUser -Force
}
Import-Module MicrosoftTeams
Connect-MicrosoftTeams | Out-Null

Write-Host "Fetching Resource Accounts..."
$appsRaw = @(Get-CsOnlineApplicationInstance -ErrorAction SilentlyContinue)

Write-Host "Fetching Phone Number Assignments..."
$assignments = @()
try {
  $assignments = @(Get-CsPhoneNumberAssignment -ErrorAction Stop)
} catch {
  Write-Warning "Get-CsPhoneNumberAssignment failed: $($_.Exception.Message)"
}

# Build lookup using every identifier Teams may expose for the Resource Account.
$phoneByTarget = @{}
foreach ($pn in $assignments) {
  $num = $pn.TelephoneNumber
  if (-not $num) { continue }
  foreach ($candidate in @(
    $pn.AssignedPstnTargetId, $pn.AssignedPstnTargetName, $pn.PstnAssignmentId,
    $pn.Identity, $pn.TargetId, $pn.TargetName, $pn.UserPrincipalName
  )) {
    if ($candidate) { $phoneByTarget[$candidate.ToString().ToLower()] = $num }
  }
}

# Merge phone numbers back onto application instances so the visualizer sees them
$apps = $appsRaw | ForEach-Object {
  $obj = $_
  $resolved = $obj.PhoneNumber
  foreach ($candidate in @($obj.ObjectId,$obj.Identity,$obj.Id,$obj.UserPrincipalName,$obj.DisplayName)) {
    if ($resolved) { break }
    if ($candidate) {
      $key = $candidate.ToString().ToLower()
      if ($phoneByTarget.ContainsKey($key)) { $resolved = $phoneByTarget[$key] }
    }
  }
  $obj | Add-Member -NotePropertyName PhoneNumber -NotePropertyValue $resolved -Force -PassThru
}

Write-Host "Fetching Auto Attendants (with full call-flow detail)..."
$aas = @(Get-CsAutoAttendant -ErrorAction SilentlyContinue -WarningAction SilentlyContinue)

Write-Host "Fetching Call Queues (with full settings)..."
$cqs = @(Get-CsCallQueue -ErrorAction SilentlyContinue -WarningAction SilentlyContinue)

Write-Host "Fetching Schedules (business hours + holidays)..."
$schedules = @()
try {
  $schedules = @(Get-CsOnlineSchedule -ErrorAction Stop -WarningAction SilentlyContinue)
} catch {
  Write-Warning "Get-CsOnlineSchedule failed: $($_.Exception.Message)"
}

Write-Host "Fetching Holidays per Auto Attendant..."
# Get-CsAutoAttendantHolidays REQUIRES -Identity — iterate per AA so it
# never prompts. Holiday schedules are also exposed via Get-CsOnlineSchedule
# above, so this is best-effort enrichment only.
$holidays = @()
foreach ($aa in $aas) {
  if (-not $aa.Identity) { continue }
  try {
    $h = Get-CsAutoAttendantHolidays -Identity $aa.Identity -ErrorAction Stop -WarningAction SilentlyContinue
    if ($h) { $holidays += $h }
  } catch { continue }
}

Write-Host "Fetching Users + Calling Settings..."
$users = @(Get-CsOnlineUser -ResultSize 2000 -ErrorAction SilentlyContinue |
  Select-Object Identity,DisplayName,UserPrincipalName,LineUri,UsageLocation,
                Department,JobTitle,EnterpriseVoiceEnabled)

# ---- Resolve every callable target ID to a human-friendly entity ---------
# Teams stores menu options / overflow / timeout / operator targets as a
# CallableEntity { Type; Id }. The Id is usually a GUID (User or
# ApplicationEndpoint) or "tel:+32..." (ExternalPstn). We pre-resolve every
# GUID we know about so the visualizer can show the actual phone number,
# display name and UPN — never a raw GUID.
$entityResolutions = @()

foreach ($a in $apps) {
  $entityResolutions += [pscustomobject]@{
    Id                = ($a.ObjectId  | Out-String).Trim()
    Identity          = ($a.Identity  | Out-String).Trim()
    Kind              = "ApplicationInstance"
    DisplayName       = $a.DisplayName
    UserPrincipalName = $a.UserPrincipalName
    PhoneNumber       = $a.PhoneNumber
  }
}

foreach ($u in $users) {
  $entityResolutions += [pscustomobject]@{
    Id                = ($u.Identity | Out-String).Trim()
    Identity          = ($u.Identity | Out-String).Trim()
    Kind              = "User"
    DisplayName       = $u.DisplayName
    UserPrincipalName = $u.UserPrincipalName
    PhoneNumber       = ($u.LineUri  -replace '^tel:','' -replace ';.*$','')
    Department        = $u.Department
    JobTitle          = $u.JobTitle
  }
}

# Distribution lists / groups referenced by call queues — resolve via Graph
# fallback (best-effort; missing groups are skipped silently).
$groupIds = @()
foreach ($cq in $cqs) {
  if ($cq.DistributionLists) { $groupIds += @($cq.DistributionLists) }
}
$groupIds = $groupIds | Select-Object -Unique
foreach ($gid in $groupIds) {
  if (-not $gid) { continue }
  try {
    $g = Get-CsGroup -Identity $gid -ErrorAction Stop
    $entityResolutions += [pscustomobject]@{
      Id          = $gid
      Identity    = $gid
      Kind        = "Group"
      DisplayName = $g.DisplayName
    }
  } catch { }
}

# Per-user forwarding / simultaneous-ring / call group settings — non-interactive
$userCallSettings = @()
$total = $users.Count
$i = 0
foreach ($u in $users) {
  $i++
  $upn = $u.UserPrincipalName
  if ([string]::IsNullOrWhiteSpace($upn)) { continue }
  if ($upn -notmatch '@') { continue }   # skip anything that wouldn't be a valid identity
  if ($i % 25 -eq 0) { Write-Host "  ...calling settings $i / $total" }
  try {
    $s = Get-CsUserCallingSettings -Identity $upn -ErrorAction Stop -WarningAction SilentlyContinue -Confirm:$false
    if (-not $s) { continue }
    $userCallSettings += [pscustomobject]@{
      UserPrincipalName    = $upn
      Identity             = $u.Identity
      IsForwardingEnabled  = $s.IsForwardingEnabled
      ForwardingType       = $s.ForwardingType
      ForwardingTargetType = $s.ForwardingTargetType
      ForwardingTarget     = $s.ForwardingTarget
      IsUnansweredEnabled  = $s.IsUnansweredEnabled
      UnansweredDelay      = $s.UnansweredDelay
      UnansweredTargetType = $s.UnansweredTargetType
      UnansweredTarget     = $s.UnansweredTarget
      Delegates            = $s.Delegates
      CallGroupOrder       = $s.CallGroupOrder
      CallGroupTargets     = $s.CallGroupTargets
      SimRingTargetType    = $s.SimRingTargetType
      SimRingTarget        = $s.SimRingTarget
    }
  } catch {
    # silently skip users we can't read (guests, service accounts, no Teams licence)
    continue
  }
}

$export = [ordered]@{
  exportedAt             = (Get-Date).ToString("o")
  microsoftTeamsModule   = (Get-Module MicrosoftTeams).Version.ToString()
  applicationInstances   = $apps
  phoneNumberAssignments = $assignments
  autoAttendants         = $aas
  callQueues             = $cqs
  schedules              = $schedules
  holidays               = $holidays
  users                  = $users
  userCallingSettings    = $userCallSettings
  entityResolutions      = $entityResolutions
}

$export | ConvertTo-Json -Depth 20 | Out-File -Encoding utf8 teams-callflow.json
Write-Host "Done — upload teams-callflow.json to the visualizer."

Requires Teams admin rights. The file is created in your current working directory.

Step 2 · Upload teams-callflow.json

Drop the file in. It's parsed locally — nothing leaves your browser.
